600mm DIA Inspection Chamber Base

MB600160

A15 – D400Load classFrom pedestrian and pedal-cycle areas to carriageways, hard shoulders and trafficked roads.

Questions on sizing or load class? Our technical team is one call away on 0121 552 8887.

Where it's used

Application areas

  • Gardens & landscaping
  • Sports & leisure
  • Driveways
  • Housing developments
  • Public realm
  • Car parks & commercial
  • Rail
  • Forecourts
  • Data centres & energy
  • Industrial & logistics

Rated A15 – D400: From pedestrian and pedal-cycle areas to carriageways, hard shoulders and trafficked roads.

Specifications

Dimensions & weight

Nominal Diameter
600mm
Depth
Up to 6.0m
Chamber Height Range
Shaft units supplied from 1m – 6m

Materials & standards

Material
Recycled Polypropylene
Colour
Black
Standards
Manufactured to EN 13598-2 & compliant
Recycled content
Yes

Loading & installation

Load class
A15 – D400
Installation
To be installed with either granular backfill or concrete surround depending on application

Connections & performance

Pipework
110mm, 150mm, 160mm
Inlet and Outlet
160mm
Main Inlet and Outlet
160mm
Jointing
Sealed rubber ring or welded joints for watertight assembly

Further specification

Base Configuration
Pre-formed benching with multi-inlet options
Access Cover
Compatible with standard access covers and frames when used in conjunction with a concrete biscuit to suit

Key features

  • 3m deep adoptable, 6.0m non-adoptable
  • Manufactured from recycled PP
  • Sealed jointing for watertight performance
  • Modular shafts for on-site depth adjustment
  • Corrosion-resistant and lightweight
  • No mechanical lifting on site
  • Integrated benching prevents debris build-up
  • Shaft units supplied from 1m – 6m
  • Accepts A15, B125, C250 & D400 covers

Specifications are for guidance. For load class selection, hydraulic design or scheme-specific advice, talk to our technical team on 0121 552 8887.
